1. Inbuilt Military Standard BMS: It has a built-in Multi-functional 120A continuous BMS, 360A for 30 sec peak, with high-quality IC and MosFET for over-current, over-discharge, over-charge, short-circuit, adverse-polarity connection, balancing functions. 2. Wide Applications: It can be used for solar energy 1
LiFePO4 batteries for solar storage: Cycle stability at high current, Fast charging within 1 hour, Deep discharge protection, overcharge protection, Voltage and temperature monitoring, Single cell monitoring, State of charge determination(SOC and SOH).
Li-ion Marine Batteries 12V 48V 240Ah: Light weight and strong power, sell to France and Russia and gain best praise, customers show it on their website to expand markets.
Item NO.:
KOK-CSB-80AHBrand:
KOK POWERShare :
Product Details
12V80AH: can start any heavy-duty vehicle including cruise yacht.
Features
Specifications
|
No. |
Items |
Specifications |
|
1 |
Nominal Voltage |
12.8V |
|
2 |
Nominal Capacity |
80Ah |
|
3 |
Cell Inside |
High Powerful Lifepo4 cell 3.2v20Ah |
|
4 |
Configuration |
4S4P |
|
5 |
Standard Charge Current |
0.2C |
|
6 |
Max. Charge Current |
1C |
|
7 |
Battery management System (BMS) |
BMS-L4S100-280 |
|
8 |
Continuous Discharge Current |
100A |
|
9 |
Discharge current for 3-5s |
400A |
|
10 |
Pulse discharge current |
1300A |
|
11 |
Full Charged Voltage |
14.6V(3.65V per cell) |
|
12 |
Charge Cut-off Voltage |
15.6V (3.9V per cell) |
|
13 |
Discharge Cut-off Voltage |
8V (2.0V per cell) |
|
14 |
Net Weight |
10.16kg |
|
14 |
Dimensions |
260*168*210mm |
|
15 |
Operating Temperature |
Charging: 0°C ~ 45°C Discharging: -20°C ~ 55°C |
|
16 |
Storage Temperature |
(Recommended to store 20 ± 5°C for long term storage) |
|
17 |
Cycle Life |
2000 times (80% of initial capacity at 0.2C rate, IEC Standard) |
Automotive, Hybrid car
Battery Customization Acceptable-We are experienced in designing various lithium battery packs for motorcycle, automotive, car audio, energy storage system(ESS) ,ebike, scooter, golf cart and any other applications to your requirements.
Lithium Battery from smartbatteryeco.com POWER have passed UN38.3, our battery including LiFePO4 motorcycle start battery, ebike battery, portable power station and solar light battery
