1. Inbuilt Military Standard BMS: It has a built-in Multi-functional 120A continuous BMS, 360A for 30 sec peak, with high-quality IC and MosFET for over-current, over-discharge, over-charge, short-circuit, adverse-polarity connection, balancing functions. 2. Wide Applications: It can be used for solar energy 1
LiFePO4 batteries for solar storage: Cycle stability at high current, Fast charging within 1 hour, Deep discharge protection, overcharge protection, Voltage and temperature monitoring, Single cell monitoring, State of charge determination(SOC and SOH).
Li-ion Marine Batteries 12V 48V 240Ah: Light weight and strong power, sell to France and Russia and gain best praise, customers show it on their website to expand markets.
Item NO.:
500WBrand:
KOK POWERShare :
|
Project
|
Parameters
|
UA300
|
UA500
|
UA1000
|
|
Battery |
Battery Category
|
Lithium ion batteries
|
||
|
Battery power
|
300 W
|
500W
|
1000W
|
|
|
Battery voltage
|
14.8 V
|
14.8 V
|
14.8 V
|
|
|
Battery safety
|
20.24Ah
|
33.8 Ah
|
67.5 Ah
|
|
|
Cycle life
|
800
|
800
|
800
|
|
|
BMS protection
|
Overvoltage, undervoltage, high and low temperature, three stage overcurrent, short circuit protection
|
|||
|
AC output |
Output voltage
|
100-240 V( Ex-factory based on region)
|
||
|
Output frequency
|
50-60 HZ( Manual switching)
|
|||
|
Output power |
300W about 20 minutes
|
500W about 40 minutes
|
1000W about 20 minutes
|
|
|
200W approximately 65 minutes
|
400W approximately 65 minutes
|
800W approximately 60 minutes
|
||
|
100W about 85 minutes
|
300W about 85 minutes
|
500W about 100 minutes
|
||
|
50W about 130 minutes
|
200W about 130 minutes
|
300W about 160 minutes
|
||
|
|
100W approximately 270 minutes
|
100W approximately 540 minutes
|
||
|
Output waveform
|
Pure sine wave
|
Pure sine wave
|
Pure sine wave
|
|
|
Conversion efficiency
|
70% load :>90%
|
|||
|
DC output |
DC5.5 port
|
DC12V5A
|
||
|
Smoke lighting interface
|
DC12V12A
|
|||
|
Conversion efficiency
|
70% load :>93%
|
|||
|
|
USB1
|
5V2.4A
|
||
|
USB output
|
USB2
|
5V2.4A
|
||
|
USB3
|
QC3.0,5-12V,18W (MAX)
|
|||
|
USB-C output
|
TYPLE-C
|
PD3.0,5-20V,60W (MAX)
|
||
|
LED lighting |
First tranche
|
5W (MAX)
|
||
|
Second tranche
|
10W (MAX)
|
|||
|
Third tranche
|
SOS
|
|||
|
Fourth tranche
|
Flash
|
|||
|
Charge |
Adapter Charge
|
19V5A approximately 4 h
|
19V5A h 6
|
19V5A approximately 12 h
|
|
Vehicle charging
|
13V8A approximately 4 h
|
13V8A h 6
|
13V8A approximately 12 h
|
|
|
Solar charging
|
20V5A h 3.5
|
20V5A h 6
|
20V5A approximately 16 h
|
|
|
Standby power
|
Static current
|
uA <100
|
uA <100
|
uA <100
|
|
Product weight
|
Net
|
4KG
|
KG 5.9
|
KG 9.9
|
|
Gross
|
5KG
|
7.5 kg
|
12KG
|
|
|
Volume of products
|
Main volume
|
200*142*146
|
200*176*146
|
200*294*146
|
|
Packing volume
|
265*265 mm 210
|
340*295*250 mm
|
mm 411*295*290
|
|
|
Use of temperature
|
Charging temperature
|
0~40℃（32~104℉）
|
||
|
|
Discharge temperature
|
-20~50℃（-4~122℉）
|
||
|
Storage temperature
|
-20~45℃（-4~113℉）
|
|||
